The oncocytic cells that we now consider to be the follicular-derived Hurthle cells were actually described by Askanazy in 1898. The term “Hurthle cells” has remained in the literature to describe follicular-derived epithelial cells with oncocytic cytology. A variety of thyroid non-neoplastic (autoimmune thyroiditis, multinodular goiter) and neoplastic conditions (Hurthle cell adenoma, Hurthle cell carcinoma) are associated with Hurthle cell cytology. We report a case of atypical hurthle cell adenoma in a 35 year old female who presented with a progressively increasing swelling in the right side of the neck for the past 1 year.

The Hurthle cell has consistently been the center of debate in the discussion of non-neoplastic and neoplastic lesions of the thyroid ever since it was first described in 1894 by Hurthle [1]. In fact, the cells originally described by Hurthle are now considered to represent ultimobranchial body-derived parafollicular cells or C cells. The oncocytic cells that we now consider to be the follicular-derived Hurthle cells were actually described by Askanazy in 1898 [2]. Despite the fact that the cells originally described by Hurthle are likely not the Hurthle cells as considered today, the term has remained in the literature to describe follicular-derived epithelial cells with oncocytic cytology. Other terms for the Hurthle cells include oncocytic, eosinophilic and oxyphilic cells [3].

A variety of thyroid non-neoplastic (autoimmune thyroiditis, multinodular goiter) and neoplastic conditions (Hurthle cell adenoma, Hurthle cell carcinoma) are associated with Hurthle cell cytology. In addition, there are several thyroid neoplasms that should be considered when one observes a Hurthle cell neoplasm in the thyroid (oncocytic variant of medullary carcinoma, several variants of papillary thyroid carcinoma) [4].

CASE SUMMARY

Fine needle aspiration cytology (FNAC) revealed a scant material comprising of thick colloid and small clusters of follicular cells along with a prominent superimposed lymphocytic infiltrate. The follicular cells cytologically were large with abundant eosinophilic, granular cytoplasm and a large hyper chromatic nucleus with a prominent nucleolus (Figure 1). Antibodies to thyroid peroxidase were found to be raised (472 IU/L). Flow cytometric analysis performed was inconclusive. In light of the above observations, a provisional diagnosis of Hashimoto’s thyroiditis with the possibility of a Hurthle cell neoplasm was made.

The patient underwent thyroidectomy. Grossly, the tissue specimen  was  a  single  encapsulated  firm  to  hard nodular mass, around 4 cm in diameter. The cut section was tan-brown in colour, solid with multiple, variably sized nodules, with central foci of haemorrhage. Microscopic examination showed a diffuse lymphocytic infiltrate with clusters and sheets of oxyphil cells which were round to oval in shape, with abundant granular cytoplasm and enlarged hyperchromatic nuclei (Figures 2 and 3). A few had prominent nucleoli. There was no evidence of capsular or vascular invasion. The final histopathological diagnosis was of Hashimoto’s thyroiditis with atypical Hurthle cell adenoma.

DISCUSSION

The Hurthle cell is a follicular-derived cell, which has a cytoplasm characterized as “swollen”. This swelling is due in large part to the presence of numerous mitochondria in the cellular cytoplasm [5,6]. These cells commonly occur in nodular goiters and dominant adenomatous or hyperplastic nodules. In our opinion, the presence of these cells should not engender a diagnosis of Hurthle cell lesion.

By electron microscopy, the cytoplasm of Hurthle cells contains several thousand mitochondria of varying size and shape. The mitochondria often show dense core granules as well as filamentous inclusions [3,7].

Hurthle cells are present in a variety of non-neoplastic conditions involving the thyroid and are not specific for any disease process. Hurthle cell metaplasia is seen in a variety of benign conditions such as autoimmune thyroiditis and multinodular goitre and in thyroids of patients that have been treated with head and neck irradiation and systemic chemotherapy [8,9]. In addition, the thyroids of patients with long-standing hyperthyroidism (Graves’ disease) may show focal or diffuse Hurthle cell change [10]. In fact, Askanazy originally described these cells in thyrotoxicosis [2]. Hurthle cells also increase with aging [11]. In some instances, one can often find an entire nodule composed of oncocytes and the distinction of hyperplasia from neoplasia can be problematic.

Most of the conditions associated with Hurthle cell change are chronic, suggesting the possibility that alteration in the follicular epithelium to take on Hurthle cell histology requires chronic stimulation [9,10].

Grossly, Hurthle cell neoplasms are usually solitary and show at least partial encapsulation. They are distinctly mahogany brown due the abundant mitochondrial cytochrome content. Lesions may vary significantly in size from one to several centimeters. Similar to oncocytic neoplasms in other organs, a central scar may be evident. Hemorrhage and necrosis may be grossly seen especially in lesions that have undergone preoperative fine-needle aspiration biopsy; massive infarction either spontaneously or following fine-needle aspiration biopsy has been reported in Hurthle cell tumors [7,9]. The infarction can be extensive, leading to severe hampering of the histologic assessment. The presence of spontaneous infarction does not equate with malignancy.

Microscopically, Hurthle cell neoplasms should be composed of at least 75% Hurthle cells. A variety of patterns of growth may be seen such as macrofollicular, follicular, trabecular, solid and pseudopapillary [11]. Many tumors will show a variety of these patterns of growth. The pattern of growth is usually follicular, but it also can be trabecular or solid. Hurthle cell neoplasms, both benign and malignant, have a tendency to show pseudopapillary change, which is felt to be an artifact from fixation and tissue processing.

One of the most difficult aspects of examining Hurthle cell neoplasms is to determine whether the lesion is benign or malignant. Size in and of itself is not predictive of behavior, although larger lesions have a higher incidence of malignancy [11,12]. It is quite clear that pathologic criteria for malignancy, such as vascular and capsular invasion, can predict the clinical behavior of these tumors [13]. Nuclear atypia, multinucleation, cellular pleomorphism, mitoses or histologic pattern of the lesion are not determinants of malignancy [14]. The main criteria for malignancy include the presence of capsular and/or vascular invasion.
